9CPZ | pdb_00009cpz

C387S variant of D-ornithine/D-lysine decarboxylase complexed with PMP and 4-guanidinobutanal

PDB DOI: https://doi.org/10.2210/pdb9CPZ/pdb

Classification: LYASE
Organism(s): Salmonella enterica subsp. enterica serovar Typhimurium
Expression System: Escherichia coli BL21(DE3)
Mutation(s): Yes

Deposited: 2024-07-18 Released: 2025-08-06
Deposition Author(s): Phillips, R.S., Blankenship, S.
Funding Organization(s): National Institutes of Health/National Institute of General Medical Sciences (NIH/NIGMS)

Experimental Data Snapshot

Method: X-RAY DIFFRACTION
Resolution: 1.54 Å
R-Value Free:
0.213 (Depositor), 0.212 (DCC)
R-Value Work:
0.168 (Depositor), 0.168 (DCC)
R-Value Observed:
0.169 (Depositor)

Starting Model: experimental
View more details

wwPDB Validation 3D Report Full Report

Ligand Structure Quality Assessment

This is version 1.0 of the entry. See complete history.

Literature

Structure of C387S DOKDC soaked with D-Arg

Phillips, R.S., Blankenship, S.

To be published.

Macromolecule Content

Total Structure Weight: 109.53 kDa
Atom Count: 8,784
Modeled Residue Count: 935
Deposited Residue Count: 956
Unique protein chains: 1

Macromolecules

Find similar proteins by:

(by identity cutoff) | 3D Structure

Entity ID: 1
Molecule	Chains	Sequence Length	Organism	Details	Image
D-ornithine/D-lysine decarboxylase	A, B	478	Salmonella enterica subsp. enterica serovar Typhimurium	Mutation(s): 1 Gene Names: dokD, STM2360 EC: 4.1.1.116
UniProt
Find proteins for Q8ZNC4 (Salmonella typhimurium (strain LT2 / SGSC1412 / ATCC 700720)) Explore Q8ZNC4 Go to UniProtKB: Q8ZNC4
Entity Groups
Sequence Clusters	30% Identity50% Identity70% Identity90% Identity95% Identity100% Identity
UniProt Group	Q8ZNC4
Sequence Annotations Expand
Reference Sequence

Small Molecules

Ligands 6 Unique
ID	Chains	Name / Formula / InChI Key	2D Diagram	3D Interactions
PMP (Subject of Investigation/LOI) Query on PMP Download Ideal Coordinates CCD File SDF format, chain F [auth A] SDF format, chain L [auth B] MOL2 format, chain F [auth A] MOL2 format, chain L [auth B] mmCIF format, chain F [auth A] mmCIF format, chain L [auth B]	F [auth A], L [auth B]	4'-DEOXY-4'-AMINOPYRIDOXAL-5'-PHOSPHATE C₈ H₁₃ N₂ O₅ P ZMJGSOSNSPKHNH-UHFFFAOYSA-N		Interactions Focus chain F [auth A] Focus chain L [auth B] Interactions & Density Focus chain F [auth A] Focus chain L [auth B]
A1AZK (Subject of Investigation/LOI) Query on A1AZK Download Ideal Coordinates CCD File SDF format, chain G [auth A] SDF format, chain J [auth B] MOL2 format, chain G [auth A] MOL2 format, chain J [auth B] mmCIF format, chain G [auth A] mmCIF format, chain J [auth B]	G [auth A], J [auth B]	N-(4-oxobutyl)guanidine C₅ H₁₁ N₃ O VCOFTLCIPLEZKE-UHFFFAOYSA-N		Interactions Focus chain G [auth A] Focus chain J [auth B] Interactions & Density Focus chain G [auth A] Focus chain J [auth B]
DMS Query on DMS Download Ideal Coordinates CCD File SDF format, chain C [auth A] SDF format, chain D [auth A] SDF format, chain H [auth B] SDF format, chain K [auth B] MOL2 format, chain C [auth A] MOL2 format, chain D [auth A] MOL2 format, chain H [auth B] MOL2 format, chain K [auth B] mmCIF format, chain C [auth A] mmCIF format, chain D [auth A] mmCIF format, chain H [auth B] mmCIF format, chain K [auth B]	C [auth A], D [auth A], H [auth B], K [auth B]	DIMETHYL SULFOXIDE C₂ H₆ O S IAZDPXIOMUYVGZ-UHFFFAOYSA-N		Interactions Focus chain C [auth A] Focus chain D [auth A] Focus chain H [auth B] Focus chain K [auth B] Interactions & Density Focus chain C [auth A] Focus chain D [auth A] Focus chain H [auth B] Focus chain K [auth B]
ACT Query on ACT Download Ideal Coordinates CCD File SDF format, chain M [auth B] MOL2 format, chain M [auth B] mmCIF format, chain M [auth B]	M [auth B]	ACETATE ION C₂ H₃ O₂ QTBSBXVTEAMEQO-UHFFFAOYSA-M		Interactions Focus chain M [auth B] Interactions & Density Focus chain M [auth B]
CL Query on CL Download Ideal Coordinates CCD File SDF format, chain N [auth B] MOL2 format, chain N [auth B] mmCIF format, chain N [auth B]	N [auth B]	CHLORIDE ION Cl VEXZGXHMUGYJMC-UHFFFAOYSA-M		Interactions Focus chain N [auth B] Interactions & Density Focus chain N [auth B]
NA Query on NA Download Ideal Coordinates CCD File SDF format, chain E [auth A] SDF format, chain I [auth B] MOL2 format, chain E [auth A] MOL2 format, chain I [auth B] mmCIF format, chain E [auth A] mmCIF format, chain I [auth B]	E [auth A], I [auth B]	SODIUM ION Na FKNQFGJONOIPTF-UHFFFAOYSA-N		Interactions Focus chain E [auth A] Focus chain I [auth B] Interactions & Density Focus chain E [auth A] Focus chain I [auth B]
