9HG1 | pdb_00009hg1

Crystal structure of M. smegmatis GMP reductase in complex with GMP and ATP.

PDB DOI: https://doi.org/10.2210/pdb9HG1/pdb

Classification: OXIDOREDUCTASE
Organism(s): Mycolicibacterium smegmatis
Expression System: Escherichia coli BL21(DE3)
Mutation(s): No

Deposited: 2024-11-18 Released: 2025-08-27
Deposition Author(s): Dolezal, M., Klima, M., Pichova, I.
Funding Organization(s): European Union (EU)

Experimental Data Snapshot

Method: X-RAY DIFFRACTION
Resolution: 2.30 Å
R-Value Free:
0.230 (Depositor), 0.229 (DCC)
R-Value Work:
0.200 (Depositor), 0.200 (DCC)
R-Value Observed:
0.201 (Depositor)

Starting Model: experimental
View more details

wwPDB Validation 3D Report Full Report

Ligand Structure Quality Assessment

This is version 1.0 of the entry. See complete history.

Literature

Structural basis for allosteric regulation of mycobacterial guanosine 5'-monophosphate reductase with ATP and GTP.

Dolezal, M., Knejzlik, Z., Kouba, T., Filimonenko, A., Svachova, H., Klima, M., Pichova, I.

To be published.

Macromolecule Content

Total Structure Weight: 842.45 kDa
Atom Count: 57,130
Modeled Residue Count: 7,568
Deposited Residue Count: 7,936
Unique protein chains: 1

Macromolecules

Find similar proteins by:

(by identity cutoff) | 3D Structure

Entity ID: 1
Molecule	Chains	Sequence Length	Organism	Details	Image
GMP reductase	A, B, C, D, E A, B, C, D, E, F, G, H, I, J, K, L, M, N, O, P	496	Mycolicibacterium smegmatis	Mutation(s): 0 Gene Names: guaB1, MSMEG_3634, MSMEI_3548 EC: 1.7.1.7
UniProt
Find proteins for A0QYE8 (Mycolicibacterium smegmatis (strain ATCC 700084 / mc(2)155)) Explore A0QYE8 Go to UniProtKB: A0QYE8
Entity Groups
Sequence Clusters	30% Identity50% Identity70% Identity90% Identity95% Identity100% Identity
UniProt Group	A0QYE8
Sequence Annotations Expand
Reference Sequence

Small Molecules

Ligands 2 Unique
ID	Chains	Name / Formula / InChI Key	2D Diagram	3D Interactions
ATP (Subject of Investigation/LOI) Query on ATP Download Ideal Coordinates CCD File SDF format, chain Y [auth E] SDF format, chain W [auth D] SDF format, chain VA [auth P] SDF format, chain U [auth C] SDF format, chain TA [auth O] SDF format, chain S [auth B] SDF format, chain RA [auth N] SDF format, chain Q [auth A] SDF format, chain PA [auth M] SDF format, chain NA [auth L] SDF format, chain KA [auth K] SDF format, chain IA [auth J] SDF format, chain GA [auth I] SDF format, chain EA [auth H] SDF format, chain CA [auth G] SDF format, chain AA [auth F] MOL2 format, chain Y [auth E] MOL2 format, chain W [auth D] MOL2 format, chain VA [auth P] MOL2 format, chain U [auth C] MOL2 format, chain TA [auth O] MOL2 format, chain S [auth B] MOL2 format, chain RA [auth N] MOL2 format, chain Q [auth A] MOL2 format, chain PA [auth M] MOL2 format, chain NA [auth L] MOL2 format, chain KA [auth K] MOL2 format, chain IA [auth J] MOL2 format, chain GA [auth I] MOL2 format, chain EA [auth H] MOL2 format, chain CA [auth G] MOL2 format, chain AA [auth F] mmCIF format, chain Y [auth E] mmCIF format, chain W [auth D] mmCIF format, chain VA [auth P] mmCIF format, chain U [auth C] mmCIF format, chain TA [auth O] mmCIF format, chain S [auth B] mmCIF format, chain RA [auth N] mmCIF format, chain Q [auth A] mmCIF format, chain PA [auth M] mmCIF format, chain NA [auth L] mmCIF format, chain KA [auth K] mmCIF format, chain IA [auth J] mmCIF format, chain GA [auth I] mmCIF format, chain EA [auth H] mmCIF format, chain CA [auth G] mmCIF format, chain AA [auth F]	AA [auth F] CA [auth G] EA [auth H] GA [auth I] IA [auth J] AA [auth F], CA [auth G], EA [auth H], GA [auth I], IA [auth J], KA [auth K], NA [auth L], PA [auth M], Q [auth A], RA [auth N], S [auth B], TA [auth O], U [auth C], VA [auth P], W [auth D], Y [auth E]	ADENOSINE-5'-TRIPHOSPHATE C₁₀ H₁₆ N₅ O₁₃ P₃ ZKHQWZAMYRWXGA-KQYNXXCUSA-N		Interactions Focus chain AA [auth F] Focus chain CA [auth G] Focus chain EA [auth H] Focus chain GA [auth I] Focus chain IA [auth J] Focus chain KA [auth K] Focus chain NA [auth L] Focus chain PA [auth M] Focus chain Q [auth A] Focus chain RA [auth N] Focus chain S [auth B] Focus chain TA [auth O] Focus chain U [auth C] Focus chain VA [auth P] Focus chain W [auth D] Focus chain Y [auth E] Interactions & Density Focus chain AA [auth F] Focus chain CA [auth G] Focus chain EA [auth H] Focus chain GA [auth I] Focus chain IA [auth J] Focus chain KA [auth K] Focus chain NA [auth L] Focus chain PA [auth M] Focus chain Q [auth A] Focus chain RA [auth N] Focus chain S [auth B] Focus chain TA [auth O] Focus chain U [auth C] Focus chain VA [auth P] Focus chain W [auth D] Focus chain Y [auth E]
5GP (Subject of Investigation/LOI) Query on 5GP Download Ideal Coordinates CCD File SDF format, chain Z [auth E] SDF format, chain X [auth D] SDF format, chain V [auth C] SDF format, chain UA [auth P] SDF format, chain T [auth B] SDF format, chain SA [auth O] SDF format, chain R [auth A] SDF format, chain QA [auth N] SDF format, chain OA [auth M] SDF format, chain MA [auth L] SDF format, chain LA [auth K] SDF format, chain JA [auth J] SDF format, chain HA [auth I] SDF format, chain FA [auth H] SDF format, chain DA [auth G] SDF format, chain BA [auth F] MOL2 format, chain Z [auth E] MOL2 format, chain X [auth D] MOL2 format, chain V [auth C] MOL2 format, chain UA [auth P] MOL2 format, chain T [auth B] MOL2 format, chain SA [auth O] MOL2 format, chain R [auth A] MOL2 format, chain QA [auth N] MOL2 format, chain OA [auth M] MOL2 format, chain MA [auth L] MOL2 format, chain LA [auth K] MOL2 format, chain JA [auth J] MOL2 format, chain HA [auth I] MOL2 format, chain FA [auth H] MOL2 format, chain DA [auth G] MOL2 format, chain BA [auth F] mmCIF format, chain Z [auth E] mmCIF format, chain X [auth D] mmCIF format, chain V [auth C] mmCIF format, chain UA [auth P] mmCIF format, chain T [auth B] mmCIF format, chain SA [auth O] mmCIF format, chain R [auth A] mmCIF format, chain QA [auth N] mmCIF format, chain OA [auth M] mmCIF format, chain MA [auth L] mmCIF format, chain LA [auth K] mmCIF format, chain JA [auth J] mmCIF format, chain HA [auth I] mmCIF format, chain FA [auth H] mmCIF format, chain DA [auth G] mmCIF format, chain BA [auth F]	BA [auth F] DA [auth G] FA [auth H] HA [auth I] JA [auth J] BA [auth F], DA [auth G], FA [auth H], HA [auth I], JA [auth J], LA [auth K], MA [auth L], OA [auth M], QA [auth N], R [auth A], SA [auth O], T [auth B], UA [auth P], V [auth C], X [auth D], Z [auth E]	GUANOSINE-5'-MONOPHOSPHATE C₁₀ H₁₄ N₅ O₈ P RQFCJASXJCIDSX-UUOKFMHZSA-N		Interactions Focus chain BA [auth F] Focus chain DA [auth G] Focus chain FA [auth H] Focus chain HA [auth I] Focus chain JA [auth J] Focus chain LA [auth K] Focus chain MA [auth L] Focus chain OA [auth M] Focus chain QA [auth N] Focus chain R [auth A] Focus chain SA [auth O] Focus chain T [auth B] Focus chain UA [auth P] Focus chain V [auth C] Focus chain X [auth D] Focus chain Z [auth E] Interactions & Density Focus chain BA [auth F] Focus chain DA [auth G] Focus chain FA [auth H] Focus chain HA [auth I] Focus chain JA [auth J] Focus chain LA [auth K] Focus chain MA [auth L] Focus chain OA [auth M] Focus chain QA [auth N] Focus chain R [auth A] Focus chain SA [auth O] Focus chain T [auth B] Focus chain UA [auth P] Focus chain V [auth C] Focus chain X [auth D] Focus chain Z [auth E]
